| Type | 50 HP (36.9kW), 2100 RPM, 3 Cylinders, Coolant cooled with overflow reservoir, Naturally Aspirated | |||
|---|---|---|---|---|
| Air – Filter | Dry type, Dual element |
| Clutch | Single / Dual | |||
|---|---|---|---|---|
| Gear Box | 8 Forward + 4 Reverse, Collarshift | |||
| Speeds | Forward 2.96 – 32.39 km/h, Reverse 3.89 – 14.90 |
| Maximum Lifting Capacity | 1600 kgf at lower link ends | |||
|---|---|---|---|---|
| 3 Point Linkage | Category II Automatic Depth & Draft Control |
| Type | Power |
|---|
| Type | Independent, 6 splines | |||
|---|---|---|---|---|
| Standard | 540 @ 2100 ERPM | |||
| Economy | 540 @ 1600 ERPM |
| Total Weight | 1870 kg | |||
|---|---|---|---|---|
| Wheel Base | 1950 mm | |||
| Overall Length | 3355 mm | |||
| Overall Width | 1778 mm | |||
| Ground Clearance | 0375 mm | |||
| Turning Radius with Brakes | 2900 mm |
| Front | 7.5 x 16 , 8PR | |||
|---|---|---|---|---|
| Rear | 14.9 x 28, 12 PR |
